Kriegsmarine — Submarine

German submarine U-1197

Type VIIC submarine

German submarine U-1197
UK Government — This photograph A 16040 comes from the collections of the Imperial War Museums — Public domain — Wikimedia Commons Plate U 570, a Type VIIC submarine.

Service

  1. Kriegsmarine as U-11972 December 1943 — 25 April 1945510 days of the war
Type VIIC submarine Particulars
Name
U-1197
Builder
F Schichau GmbH, Danzig
Ordered
25 August 1941
Laid down
13 March 1943
Launched
30 September 1943
Commissioned
2 December 1943
Decommissioned
25 April 1945
Fate
Captured in May 1945
Sunk in February 1946 (1945)
Status
Unknown

Specifications

Displacement, surfaced
757 long tons (769 t)
Displacement, submerged
857 long tons (871 t)
Length
67.1 m (220.1 ft) OA
Beam
6.2 m (20.3 ft)
Draught
4.74 m (15.6 ft)
Speed
17.7 knots (32.8 km/h, 20.4 mph)
Range
8,500 nmi (15,742 km)
Main gun
88 mm (3.5 in)

U-1197 was a Type VIIC submarine in service with the Kriegsmarine. Her keel was laid at F Schichau GmbH, Danzig on 13 March 1943. Launched on 30 September 1943, she entered service on 2 December 1943.

612 ships of the class were built. The class followed the Type UB III, Vetehinen class and was succeeded by the Type XXI (Late-war replacement).

The boat displaced 757 long tons surfaced and 857 long tons submerged. She measured 67.1 m (220 ft) long with a beam of 6.2 m (20 ft). Her designed speed was 17.7 knots.

Her main battery was one 88 mm (3.5 in) guns.

She was in commission for 510 days of the Second World War. She was decommissioned on 25 April 1945.

She was captured in May 1945.

Written from the harvested record. Every figure above is sourced; the wording is this site's own.

Armament and machinery

Armament and machinery
Propulsion
  • 2 shafts
  • 2 × diesel engines
  • 2 × electric motors
Power
  • 2800 - 3200 PS (diesels)
  • 750 PS (electric)
Armament
  • 5 × 53.3 cm torpedo tubes (four bow, one stern)
  • 14 × torpedoes or
  • 26 TMA mines
  • 1 × 8.8 cm deck gun (220 rounds)
  • 1 × 3.7 cm Flak M42 AA gun
  • 2 × twin 2 cm C/30 anti-aircraft guns

Sister ships

587 more in the class
