German submarine U-1209

Type VIIC submarine

German submarine U-1209
UK Government — This photograph A 16040 comes from the collections of the Imperial War Museums — Public domain — Wikimedia Commons Plate U 570, a Type VIIC submarine.

Service

  1. Kriegsmarine as U-120913 April 1944 — 18 December 1944249 days of the war
Type VIIC submarine Particulars
Name
U-1209
Builder
F Schichau GmbH, Danzig
Ordered
2 April 1942
Laid down
14 July 1943
Launched
9 February 1944
Commissioned
13 April 1944
Fate
Scuttled on 18 December 1944 (1944)
Status
Wreck

Specifications

Displacement, surfaced
757 long tons (769 t)
Displacement, submerged
857 long tons (871 t)
Length
67.1 m (220.1 ft) OA
Beam
6.2 m (20.3 ft)
Draught
4.74 m (15.6 ft)
Speed
17.7 knots (32.8 km/h, 20.4 mph)
Range
8,500 nmi (15,742 km)
Main gun
88 mm (3.5 in)

U-1209 was a Type VIIC submarine of the Kriegsmarine. Her keel was laid at F Schichau GmbH, Danzig on 14 July 1943. She entered service on 13 April 1944, having been launched on 9 February 1944.

612 ships of the class were built. The class followed the Type UB III, Vetehinen class and was succeeded by the Type XXI (Late-war replacement).

The boat displaced 757 long tons surfaced and 857 long tons submerged. She measured 67.1 m (220 ft) long with a beam of 6.2 m (20 ft). Her designed speed was 17.7 knots.

Her main battery was one 88 mm (3.5 in) guns.

She was in commission for 249 days of the Second World War.

She was scuttled on 18 December 1944. The wreck survives.

Written from the harvested record. Every figure above is sourced; the wording is this site's own.

Armament and machinery

Armament and machinery
Propulsion
  • 2 shafts
  • 2 × diesel engines
  • 2 × electric motors
Power
  • 2800 - 3200 PS (diesels)
  • 750 PS (electric)
Armament
  • 5 × 53.3 cm torpedo tubes (four bow, one stern)
  • 14 × torpedoes or
  • 26 TMA mines
  • 1 × 8.8 cm deck gun (220 rounds)
  • 1 × 3.7 cm Flak M42 AA gun
  • 2 × twin 2 cm C/30 anti-aircraft guns

Sister ships

587 more in the class
