Recognition Guide Warships of the Second World War
Imperial Japanese Navy — Light cruiser

Japanese cruiser Agano

Agano-class cruiser light cruiser

Japanese cruiser Agano
Imperial Japanese Navy official photograph — Mikasa Memorial Museum archives, Yokosuka, Japan — Public domain — Wikimedia Commons Plate Japanese light cruiser Agano off Sasebo in October 1942.

Service

  1. Imperial Japanese Navy as Agano31 October 1942 — 31 March 1944517 days of the war
Agano-class cruiser light cruiser Particulars
Name
Agano
Namesake
Agano River
Builder
Sasebo Naval Arsenal
Ordered
1939
Laid down
18 June 1940
Launched
22 October 1941
Commissioned
31 October 1942
Struck
31 March 1944
Fate
Sunk, 15 February 1944 (1944)
Status
Wreck

Specifications

Displacement, standard
6,547 long tons (6,652 t)
Displacement, full load
8,399 long tons (8,534 t)
Length
174.1 m (571.2 ft) OA
Beam
15.2 m (49.9 ft)
Draught
5.63 m (18.5 ft)
Speed
35 knots (64.8 km/h, 40.3 mph)
Range
6,300 nmi (11,668 km)
Complement
700
Main gun
150 mm (5.9 in)

Agano was a Agano-class cruiser light cruiser built for the Imperial Japanese Navy. The ship was named after Agano River. Sasebo Naval Arsenal laid her keel on 18 June 1940. She entered service on 31 October 1942, having been launched on 22 October 1941.

Her class ran to four ships. The class followed the Sendai-class cruiser and was succeeded by the Ōyodo-class cruiser.

She displaced 6,547 long tons standard and 8,399 long tons at full load. She measured 174.1 m (571 ft) long with a beam of 15.2 m (50 ft). Her designed speed was 35 knots, and she carried a complement of 700.

Her main battery was six 150 mm (5.9 in) guns in three twin mountings. She carried two aircraft. Her machinery developed 100,000 shp through four shafts.

She was in commission for 517 days of the Second World War. She was struck from the register on 31 March 1944.

She was sunk on 15 February 1944, at 10°11′N 151°42′E. The wreck survives.

Written from the harvested record. Every figure above is sourced; the wording is this site's own.

Armament and machinery

Armament and machinery
Propulsion
  • 4 shafts; 4 geared steam turbine sets
Power
  • 6 water-tube boilers
  • 100000 shp
Armament
  • 3 × twin 15 cm guns
  • 2 × twin 8 cm (3 in) AA guns
  • 2 × triple 2.5 cm AA guns
  • 2 × twin 13.2 mm AA MGs
  • 2 × quadruple 61 cm torpedo tubes
  • 2 × depth charge chutes, 18 depth charges
  • 3 × mines
Armour
  • Belt 60 mm
  • Deck 20 mm
Aircraft
  • 2 × floatplanes

Sister ships

Sources

  • Facts harvested from Japanese cruiser Agano on Wikipedia. Figures only — no wording is taken from it.
  • Photograph: Imperial Japanese Navy official photograph — Mikasa Memorial Museum archives, Yokosuka, Japan — Public domain — Wikimedia Commons
