German submarine U-1406
Service
- as U-14068 February 1945 — 5 May 194586 days of the war
- Name
- U-1406
- Builder
- Blohm & Voss, Hamburg
- Ordered
- 4 January 1943
- Laid down
- 30 October 1943
- Launched
- 2 January 1945
- Commissioned
- 8 February 1945
- Fate
- Surrendered on 5 May 1945 at Cuxhaven
Scuttled on 7 May 1945
Raised and broken up after 18 May 1948 (1945) - Status
- Wreck
Specifications
- Displacement, standard
- 408 long tons (415 t)
- Displacement, surfaced
- 307 long tons (312 t)
- Displacement, submerged
- 332 long tons (337 t)
- Length
- 41.45 m (136 ft) OA
- Beam
- 4.5 m (14.8 ft)
- Draught
- 4.3 m (14.1 ft)
- Speed
- 8.8 knots (16.3 km/h, 10.1 mph)
- Range
- 3,000 nmi (5,556 km)
- Complement
- 19
U-1406 was a Type XVIIB submarine built for the Kriegsmarine. Her keel was laid at Blohm & Voss, Hamburg on 30 October 1943. She entered service on 8 February 1945, having been launched on 2 January 1945.
She was one of eight ships of her class. The class followed the Type II (Conventional coastal submarine) and was succeeded by the Type XXIII (conventional coastal submarine).
The boat displaced 307 long tons surfaced and 332 long tons submerged. She measured 41.5 m (136 ft) long with a beam of 4.5 m (15 ft). Her designed speed was 8.8 knots, and she carried a complement of 19.
Her main battery was two 533 mm (21.0 in) guns.
She was in commission for 86 days of the Second World War.
She was scuttled on 5 May 1945. The wreck survives.
Written from the harvested record. Every figure above is sourced; the wording is this site's own.
Armament and machinery
Armament and machinery
- Propulsion
- 1 × Deutz SAA 8M517 supercharged 8-cylinder diesel engine (surface diesel drive)
- 1 × AEG Maschine AWT98 electric motor (submerged electric drive)
- 1 × Walter gas turbines HTP (submerged HTP drive)
- 1 shaft
- Power
- 210 PS (surface diesel drive)
- 77 PS (submerged electric drive)
- 2500 PS (submerged HTP drive)
- Armament
- 2 × 53.3 cm torpedo tubes (bow)
- 4 × torpedoes
Sister ships
