German submarine U-506
Service
- as U-50615 September 1941 — 12 July 1943665 days of the war
- Name
- U-506
- Builder
- Deutsche Werft, Hamburg
- Ordered
- 25 September 1939
- Laid down
- 11 July 1940
- Launched
- 20 June 1941
- Commissioned
- 15 September 1941
- Fate
- Sunk on 12 July 1943 (1943)
- Status
- Wreck
Specifications
- Displacement, surfaced
- 1,102 long tons (1,120 t)
- Displacement, submerged
- 1,213 long tons (1,232 t)
- Length
- 76.76 m (251.8 ft) OA
- Beam
- 6.76 m (22.2 ft)
- Draught
- 4.7 m (15.4 ft)
- Speed
- 18.2 knots (33.7 km/h, 20.9 mph)
- Range
- 13,450 nmi (24,909 km)
- Complement
- 48
- Main gun
- 105 mm (4.1 in)
U-506 was a Type IXC submarine in service with the Kriegsmarine. Her keel was laid at Deutsche Werft, Hamburg on 11 July 1940. She entered service on 15 September 1941, having been launched on 20 June 1941.
Her class ran to 142 ships. The class followed the Type I and was succeeded by the Type XXI.
The boat displaced 1,102 long tons surfaced and 1,213 long tons submerged. She measured 76.8 m (252 ft) long with a beam of 6.8 m (22 ft). Her designed speed was 18.2 knots, and she carried a complement of 48.
Her main battery was one 105 mm (4.1 in) guns.
She was in commission for 665 days of the Second World War.
She was sunk on 12 July 1943, at 42°30′N 16°30′W. The wreck survives.
Written from the harvested record. Every figure above is sourced; the wording is this site's own.
Armament and machinery
Armament and machinery
- Propulsion
- 2 shafts
- 2 × diesel engines
- 2 × electric motors
- Power
- 4400 PS (diesels)
- 1000 PS (electric)
- Armament
- 6 × torpedo tubes (4 bow, 2 stern)
- 22 × 53.3 cm torpedoes
- 1 × 10.5 cm SK C/32 deck gun (180 rounds)
- 1 × 3.7 cm SK C/30 AA gun
- 1 × twin 2 cm FlaK 30 AA guns
