German submarine U-513
Service
- as U-51310 January 1942 — 19 July 1943555 days of the war
- Name
- U-513
- Builder
- Deutsche Werft, Hamburg
- Ordered
- 14 February 1940
- Laid down
- 26 April 1941
- Launched
- 29 October 1941
- Commissioned
- 10 January 1942
- Fate
- Sunk on 19 July 1943 (1943)
- Status
- Wreck
Specifications
- Displacement, surfaced
- 1,102 long tons (1,120 t)
- Displacement, submerged
- 1,213 long tons (1,232 t)
- Length
- 76.76 m (251.8 ft) OA
- Beam
- 6.76 m (22.2 ft)
- Draught
- 4.7 m (15.4 ft)
- Speed
- 18.3 knots (33.9 km/h, 21.1 mph)
- Range
- 13,450 nmi (24,909 km)
- Complement
- 48
- Main gun
- 105 mm (4.1 in)
U-513 was a Type IXC submarine, operated by the Kriegsmarine. Deutsche Werft, Hamburg laid her keel on 26 April 1941. Launched on 29 October 1941, she entered service on 10 January 1942.
142 ships of the class were built. The class followed the Type I and was succeeded by the Type XXI.
The boat displaced 1,102 long tons surfaced and 1,213 long tons submerged. She measured 76.8 m (252 ft) long with a beam of 6.8 m (22 ft). Her designed speed was 18.3 knots, and she carried a complement of 48.
Her main battery was one 105 mm (4.1 in) guns.
She was in commission for 555 days of the Second World War.
She was sunk on 19 July 1943, at 27°17′S 47°32′W. The wreck survives.
Written from the harvested record. Every figure above is sourced; the wording is this site's own.
Armament and machinery
Armament and machinery
- Propulsion
- 2 shafts
- 2 × diesel engines
- 2 × electric motors
- Power
- 4400 PS (diesels)
- 1000 PS (electric)
- Armament
- 6 × torpedo tubes (4 bow, 2 stern)
- 22 × 53.3 cm torpedoes
- 1 × 10.5 cm SK C/32 deck gun (180 rounds)
- 1 × 3.7 cm SK C/30 AA gun
- 1 × twin 2 cm FlaK 30 AA guns
