Recognition Guide Warships of the Second World War
Regia Marina — Cruiser

Italian cruiser Zara

Zara-class cruiser

Italian cruiser Zara
Unknown author — history.navy.mil — Public domain — Wikimedia Commons Plate The Italian cruiser Zara , date unknown.

Service

  1. Regia Marina as Zara20 October 1931 — 29 March 1941574 days of the war
Zara-class cruiser Particulars
Name
Zara
Builder
Odero Terni Orlando, Muggiano
Laid down
4 July 1929
Launched
27 April 1930
Commissioned
20 October 1931
Fate
Sunk, 29 March 1941 (1941)
Status
Wreck

Specifications

Displacement, standard
11,680 long tons (11,867 t)
Displacement, full load
14,300 long tons (14,529 t)
Length
182.8 m (599.7 ft)
Beam
20.6 m (67.6 ft)
Draught
7.2 m (23.6 ft)
Speed
33 knots (61.1 km/h, 38 mph)
Range
5,361 nmi (9,929 km)
Complement
841
Main gun
203 mm (8 in)

Zara was a Zara-class cruiser of the Regia Marina. Her keel was laid at Odero Terni Orlando, Muggiano on 4 July 1929. Launched on 27 April 1930, she entered service on 20 October 1931.

Her class ran to four ships. The class followed the Trento-class cruiser and was succeeded by the Italian cruiser Bolzano.

Displacement was 11,680 long tons standard and 14,300 long tons at full load. She measured 182.8 m (600 ft) long with a beam of 20.6 m (68 ft). Her designed speed was 33 knots, and she carried a complement of 841.

Her main battery was eight 203 mm (8.0 in) guns. Her belt armour was 150 mm (5.9 in) and her deck 70 mm. She carried two aircraft. Her machinery developed 95,000 shp.

She was in commission for 574 days of the Second World War.

She was sunk on 29 March 1941, at 35°20′N 20°57′E. The wreck survives.

Written from the harvested record. Every figure above is sourced; the wording is this site's own.

Armament and machinery

Armament and machinery
Propulsion
  • 2 × Parsons steam turbines
  • 2 × screw propellers
Power
  • 95000 shp
  • 8 × 3-drum Thornycroft boilers
Armament
  • 8 × 203 mm/53 cal. guns
  • 16 × 100 mm / 47 caliber guns
  • 6 × Vickers-Terni 40 mm/39 guns
  • 8 × 13.2 mm machine guns
Armour
  • Deck: 70 mm
  • Belt: 150 mm
  • Turret faces: 150 mm
  • Barbettes: 150 mm
Aircraft
  • 2
